Mini H5 Wireless Camera Infrared 720P Micro camera Camcorder Night Vision flexible motion sensor HD cam spy hidden camera Features: Video resolution: HD 1280 * 720 Video format: MP4 (h.264 encoded) Sensor type: COMS Viewing angle: 150 Degree MICROPHONE: noise reduction microphone Remote control: remote control & IP AP connection Dimension: 44 * 44 * 14mm Weight: 40g Battery: Built-in 600 mAHAt Home.
- Insert a Micro SD Card, Class6 or above ( Maximum 64 GB).
- Full Charge the camera for about 2 hours until the Red indicator goes out.
3. power on: press and hold ON / OFF button for 3 seconds, startup time is about 25 seconds, Green & Blue Mode indicator flashes continuously during startup. Green indicator goes on after the initialization has finished.
4. Press the Mode Switch can change the Working Mode (Video / Photo / Motion Sensor)
5. Power off: Press ON / OFF button for 3 seconds
Basic operation
When the camera is in the mode Standby (the Green indicator is lit), press the ON / OFF button once, the green indicator goes off, the camera starts recording video.
Press ON / OFF button again to stop recording, Green Mode indicator continues, the camera will return to Standby mode. The video file will be saved every 5 minutes.
When the camera is in Standby mode (the Green indicator is on), then press the WI-FI button, the green indicator turns off after the Green indicator flashes 5 seconds, the camera takes pictures every second of 15 (Green indicator mode flashes once).
When the camera is in Standby mode (the Green indicator is on), then press the WI-FI button, all indicators will turn off, the camera will start motion detection
The Red indicator remains lit during charging, when the charge is complete it will turn off.
- Power in the process: After the camera's initialization, the Green indicator is lit. After 8 seconds, Blue & Green indicator slowly. The camera will find the network, if it does, the Blue indicator will flash slowly. If not, blue indicator will continue.
- Power off: press and hold the ON / OFF button for 3 seconds. Before hanging up, the last video will be saved.
- Please use 5V / 1A adapter from legal manufacturer to charge the camera.
